With the DDR-RAM-DIMM socket with ECC support for up to 1 GB, standard desktop memory modules can be used. In addition, JRex-PM offers the Intel® 855GM chipset, a 400MHz front-side bus, the fastest IDE via UDMA/100 and USB 2.0. The JRex-PM single-board computer, with easily controllable heat dissipation and excellent EMC values, has thereby reached a new level of performance for embedded systems. The 1.6GHz Pentium® M processor has a 2.7GHz Pentium® 4 performance with a 1.2GHz Pentium® III power consumption (18-25 W). Kontron´s 3.5" CPU board is equipped with a Pentium® M processor, part of Intel® CentrinoTM mobile technology, making it the fastest single-board computer of its class with a relatively low power consumption.

Imperx frame grabber full#

Imperx additionally offers full support with the purchase of Imperx CCD cameras.

Applications in the security sector for vehicle recognition, human recognition, tunnel monitoring and optical navigation systems are only a few of the many potential uses for this bundle.Įach component of the bundle is currently available from its respective manufacturer or from local distributors. According to the two companies, this new bundle is ideal for use in industrial applications in the fields of QA, production automation, materials flow control and machine control. By launching the embedded bundle, the two companies hope to expand beyond the military market. This extremely robust and reliable bundle is currently being used in US Navy Unmanned Aerial Vehicles. SAN DIEGO, CA-October 25, 2004, Kontron, a market leader in embedded computer technology, announces the availability of a high-performance imaging platform that bundles Kontron´s JRex-PM 3.5" Intel® Pentium® M-based CPU with the FrameLink-J-FLEX card from Imperx. Your whole order will ship together.Kontron Offers 3.5" Bundle for Industrial Image Processingģ.5" Pentium® M CPU board from Kontron is bundled with a high-speed frame grabber card from Imperx to provide a robust and reliable imaging platform The NTSC / PAL analog video signal is available at the MCX connector.Īpproximately 5 Weeks from when your order is placed. Digital data is available at the Mini-Camera Link connector. The Camera Link accessory outputs both analog and digital video simultaneously. The Camera Link module is effectively a pixel-in, pixel-out device – lines are not buffered.

Imperx frame grabber software#

The ImperX frame grabber comes with FrameLink Express software that allows for recording single or multiple images (BMP, JPG, TIF, and RAW) as well as standard AVI clips. Third-party software must be used for digital data acquisition. Camera control, external frame sync, and power through the Camera Link connector are not supported. It is important to note that the Camera Link module provides access to digital data only, and the other portions of the Base Camera Link specifications are not met. FLIR has tested the ImperX FrameLink Express model VCE-CLEX01 frame grabber (). The digital data complies with Base Camera Link standards and should be compatible with any brand Camera Link frame grabber and software. The Baud Rate is selected using auto-Baud and the camera will communicate at the first Baud Rate in which it receives a valid command until it is powered off.

Imperx frame grabber serial#

The camera uses serial communication by creating a virtual COM Port on the computer used for USB communications. The Boson camera is powered through the mini-USB connector. (There are too many options and possible combinations of HW, SW.) Note that the module does not include a Camera Link cable, frame grabber, or data acquisition/processing software. Besides a Mini-Camera Link connector for digital video, the Camera Link Module includes a mini-USB connector for power and communications, and an MCX connector for analog video. The Camera Link Module takes CMOS-type digital data from the Boson camera and converts it to Camera Link format digital video.

Imperx frame grabber Pc#

The FLIR Camera Link expansion board can be used to acquire 16-bit digital video from a Boson camera directly into a PC that is equipped with a Camera Link frame grabber.
